XMW BPF-4000-200 C-Band Pass Filter (Compare to Norsat BPF-C-6)

XMW BPF-4000-200 C-Band Pass Filter (Compare to Norsat BPF-C-6)

RF Filter

XMW provides a comprehensive line of products for C-Band Pass Filter.  FREQUENCY FILTER   OUTLINE DRAWING SPECIFICATION Center Frequency  4100MHz Bandwidth   200MHz Frequency Range 4000 - 4200 MHz Insertion Loss   0.5dB max  Return loss in band  15dB min  Rejection@CF±200MHz                     ...

USD 298.00
  • Category: Accessories, All Products, Featured products, Installation Accessories, RF Filter

XMW provides a comprehensive line of products for C-Band Pass Filter.

FREQUENCY FILTER

XMW BPF-3977-446 C-Band Pass Filter (Equal to Norsat BPF-C-3)



OUTLINE DRAWING

SPECIFICATION

Center Frequency

4100MHz

Bandwidth

200MHz

Frequency Range

4000 - 4200 MHz

Insertion Loss

 0.5dB max

 Return loss in band

 15dB min

 Rejection@CF±200MHz

                     @CF±300MHz

                     @CF±350MHz

                     @~8GHz



25dB min

60dB min

70dB min

70dB min



Flanges

In: CPR229G, Out: CPR229F

Weight

650g
