XMW BPF-3970-500 C-Band Pass Filter (Compare to Norsat BPF-C-1)

XMW BPF-3970-500 C-Band Pass Filter (Compare to Norsat BPF-C-1)

RF Filter

XMW provides a comprehensive line of products for C-Band Pass Filter.  FREQUENCY FILTER OUTLINE DRAWING SPECIFICATION Center Frequency  3950MHz Bandwidth   500MHz Frequency Range 3700 to 4200 MHz Insertion Loss   0.5dB max  Return loss in band  15dB min  Rejection@CF±300MHz                      @CF±400MHz...

USD 269.00
  • Category: Accessories, All Products, Featured products, Installation Accessories, RF Filter

XMW provides a comprehensive line of products for C-Band Pass Filter.

FREQUENCY FILTER

BPF-3970-500 BPF-C-1

OUTLINE DRAWING

SPECIFICATION

Center Frequency

3950MHz

Bandwidth

500MHz

Frequency Range

3700 to 4200 MHz

Insertion Loss

 0.5dB max

 Return loss in band

 15dB min

 Rejection@CF±300MHz

                     @CF±400MHz

                     @CF±450MHz

                     @~8GHz



25dB min

60dB min

70dB min

70dB min



Flanges

In: CPR229G, Out: CPR229F

Weight

650g
