XMW BPF-3912.5-575 C-Band Pass Filter (Compare to Norsat BPF-C-2)
XMW BPF-3912.5-575 C-Band Pass Filter (Compare to Norsat BPF-C-2)
RF Filter
XMW provides a comprehensive line of products for C-Band Pass Filter. FREQUENCY FILTER OUTLINE DRAWING SPECIFICATION Center Frequency 3912.5MHz Bandwidth 575MHz Frequency Range 3625 to 4200 MHz Insertion Loss 0.5dB max Return loss in band 15dB min Rejection@CF±300MHz @CF±400MHz...
USD 269.00
- SKU::
- Category: Accessories, All Products, Featured products, Installation Accessories, RF Filter
XMW provides a comprehensive line of products for C-Band Pass Filter.
FREQUENCY FILTER
OUTLINE DRAWING
SPECIFICATION
|
Center Frequency |
3912.5MHz |
|
Bandwidth |
575MHz |
|
Frequency Range |
3625 to 4200 MHz |
|
Insertion Loss |
0.5dB max |
|
Return loss in band |
15dB min |
|
Rejection@CF±300MHz @CF±400MHz @CF±450MHz @~8GHz |
25dB min 60dB min 70dB min 70dB min
|
|
Flanges |
In: CPR229G, Out: CPR229F |
|
Weight |
650g |
