Wideye Safari Vehicular BGAN Terminal

Wideye Safari Vehicular BGAN Terminal

Request for a quote

SKU: WID-SAFARI

The SAFARI™ is a Land Vehicular BGAN Terminal operating on the Inmarsat BGAN Satellite Network.

The SAFARI™ has one of the smallest Land Vehicular BGAN antennas in the market at 252 mm Dia x 119.12 mm H (9.9 in. Dia x 4.7 in. H) and weighs only 1.9kg (4.2 lbs.). The complete system consists of three fully integrated units – an IP44 rated Transceiver Unit (TU) with built-in Wi-Fi, an IP66 rated Handset and an IP56 rated roof mounted Antenna Unit (AU). The Antenna Unit is compact and lightweight, ideal for vehicles on-the-move. It has been designed for the most demanding environments – and is easy to carry when traveling to various locations around the world.

The SAFARI™ Land Vehicular BGAN Terminal offers the user standard voice (4kbps AMBE+2), optional 3.1 KHz high quality voice/fax, high speed Streaming and Standard IP data service for various applications, including internet browsing, email and file transfer functions.

The terminal allows simultaneous use of all services including voice/fax, data and SMS. Physical interfaces include, 2 x RJ-11 for Voice and Fax, 2 x RJ45 for Ethernet LAN connections, a RS232 port for GPS output and 4 x GPIOs, for external control or indications.



SPECIAL FEATURES

  • Forced Dialing
  • Restricted Dialing
  • Call Prioritisation
  • Remote Access
  • Backup/Restore of Configuration Settings
  • Remote Transmitter Off via GPIO
  • SIM Lock based on IMSI/DP Code/SP Code/APN
  • Multilingual WebConsole (English, Spanish, Chinese (Simplified & Traditional))
  • Multi-User access with configurable access rights
  • Time/Volume limited data sessions
  • Firewall
  • Fleet Tracking Capability - Geofencing, up to 10 polygon areas can be configured
  • MAC Filtering
  • Port Forwarding
  • Hands Free Operation

CAPABILITIES

  • Device Capabilities Internet, Email, Phone, FTP, FoIP (Fax), SMS Text, Video Streaming
  • Internet Speeds Up to 448/464 Kbps (send/receive) – Link to BGAN Service Plans
  • Global Voice 4 Kbps AMBE +2 (Uses included 2-wire IP-66 phone)
  • Streaming CIR 1:1 Speeds Options of 32, 64 and 128 Kbps.

INTERFACES

  • Ethernet 2 – RJ-45 POE (Power Over Ethernet)
  • Phone ports 1 for handset, 2 for RJ-11 for standard analog phones
  • SMS Texting Up to 160 characters (3G standard)
  • Streaming Services 32, 64 and 128 Kbps
  • Router Single or multi-user with NAT & DHCP on/off options, MAC filtering
  • Wireless 802.11 b,g (100 meters. 200 meters possible), 64 + 128 WEP security,

PHYSICAL

  • Turning Rate 60° per second
  • Controller to Antenna Cable Length 3 Meters – Flexible and narrow (may fit in most car door jambs)
  • Water and Dust Rating – Antenna IP 66
  • Operational Temperature -13° to 131° F (-25°C to 55°C)
  • Storage Temperature -40° to 85° C
  • Max Power Consumption – Operating 60 Watts
  • DC Input Power 10.8 to 32 Volts DC (Vehicle Battery)
  • Humidity 95% non-condensing at 40°C
  • Antenna Dimensions 9.9″ Diameter 4.7″ Height (252 x 119.2 mm)
  • Controller (Transceiver) Dimensions 13.4″ x 10″ x 2.4″ (340 x 253 x 61.5 mm)
  • Static / Public IP’s Optional… Up to 11
