Promax RANGERNeo 2: Field strength meter (19” rack version)

Promax RANGERNeo 2: Field strength meter (19” rack version)

Spectrum Analyzer

19” rack version of the RANGERNeo 2, 6th generation of TV & Satellite analysers. Dramatically fast spectrum analyser. It covers DVB-T/C/S, as well as DVB-T2/C2/S2. HDMI, IPTV, ASI-TS, Encrypted channels, Dolby digital Plus... allows displaying multiple screens in 7” split...

USD 7,006.00
  • Category: Accessories, All Products, Featured products, New Arrivals, Promax Electronics, Spectrum Analyzer

19” rack version of the RANGERNeo 2, 6th generation of TV & Satellite analysers. Dramatically fast spectrum analyser. It covers DVB-T/C/S, as well as DVB-T2/C2/S2. HDMI, IPTV, ASI-TS, Encrypted channels, Dolby digital Plus... allows displaying multiple screens in 7” split screen format.

SPECIFICATIONS RANGERNeo 2
OPERATION MODES Hybrid operation: 7” touch screen or conventional buttons
DIGITAL STANDARDS - DVB-T, DVB-T2, DVB-T2 lite
- DVB-C, DVB-C2, J83 Annex C QAM
- DVB-S, DVB-S2, DVB-S2 multistream, DSS
DOLBY DIGITAL PLUS Included
CONNECTIVITY - Universal RF input
- TS-ASI input and output
- IPTV input
- HDMI output
- Analog audio/video input and output
- Common Interface slot (CAM modules)
- USB interface
FUNCTIONS - Merogram and Spectrogram
- Constellation diagram for all DVB standards
- LTE filters
- Dynamic echoes analysis
- StealthID (instant signal identification)
- DVB-S2 multistream
- PLS (physical layer scrambling)
- Ultra fast spectrum analyser
  (90 ms sweep time) with peak hold
- FM RDS radio measurements
- Signal monitoring
- Field strength
- Task planner
- H.265 detection
OPTIONS - Optical fibre measurements
- 3 GHz band extender
- DAB/DAB+ radio measurements
OPTICAL FIBRE (optional) - Integrated optical-to-RF converter
- Integrated selective optical power meter
ASI-TS INPUT AND OUTPUT - Real-time transport stream analysis function
IPTV INPUT - Ethernet 100/1000 Mbps
- RJ45 connector
- UDP or RTP/UDP protocols
- MULTICAST / IGMP v2 transmission methods
- Payload: from 1 to 7 MPEG-2 packets
PC CONNECTION (via USB interface) - NetUpdate 4 free software
- Free and automatic firmware updates
- Datalogger data download
- Channel tables customization
- Measurement reports
