Norsat WAYFARER 1.8m Ku-Band Auto Flyaway Antenna
The Norsat WAYFARER™ commercial 1.8m fly-away antenna is a fast deploying, easy-to-use, and compact SATCOM VSAT. This terminal is an excellent choice for commercial applications in various industries.
fly-away antenna offers excellent rugged and reliable satellite links. Ideally suited for remote enterprise, energy, emergency, and media applications.
| WFA180KU-IEC Key Specifications | |
|---|---|
| Acquisition And Tracking | Automatic |
| Band | Ku-Band |
| Product Family | WFA180KU-IEC |
| Receive Frequency | Ku Band: 10.70 - 12.75 GHz |
| Reflector Diameter | 1.8 m |
| Transmit Frequency | Ku-Band: 13.75 - 14.50 GHz |
| Antenna Specifications |
|
| Azimuth Range | +/- 180° |
| Cross Polarization Isolation | ≥35 dB |
| Elevation Range | 0 - 90° |
| Feed Configuration | Centre-feed |
| Movement Overrides | Manual (Azimuth/Elevation) |
| Polarization | Linear +/- 90° |
| Standard Buc Options | 8W, 20W, 40W, 80W |
| Standard Lnb Options | 1000H or HS1000 |
| RF Specifications |
|
| Movement Platform | Motorized Elevation over Azimuth |
| Rx Gain | 45.3+ 20log(f/12.5)dBi |
| Tx Gain | 46.3+ 20log(f/14.25)dBi |
| Interface Specifications | |
| Interfacility Link Cable | 10 m |
| Environmental Specifications |
|
| Humidity | 0 - 95% (20°C) |
| Temperature Operational | -30°C to +60°C (Antenna) |
| Weatherproofing | IP65 |
| Windspeed Operational | 40 km/h |
| Windspeed Survival | 65 km/h |
| Physical Specifications | |
| Number Of Cases | 6 standard |
