Norsat SigmaLink 1.8m Ku-Band Manual Flyaway Antenna
The new Norsat SigmaLink Lite™ is the latest in a series of transportable satellite terminals. The SigmaLink Lite™ is ideally suited to provide broadband connectivity for base camps or other prolonged missions where assignments are temporary but deployment is protracted. With simple setup and automatic acquisition, personnel with minimal training can have the SigmaLink Lite™ up and transmitting in minutes.
| SLL180KU Key Specifications | |
|---|---|
| Acquisition And Tracking | Manual |
| Band | Ku-Band |
| Product Family | SLL180KU |
| Receive Frequency | Ku-Band: 10.95 - 12.75 GHz |
| Reflector Diameter | 1.8 m |
| Transmit Frequency | Ku-Band: 13.75 - 14.50 GHz |
| Antenna Specifications |
|
| Azimuth Range | +/- 180° |
| Cross Polarization Isolation | >85 dB (Tx); >35 dB (Rx) |
| Elevation Range | 10° - 90° |
| Feed Configuration | 2-port circular |
| Polarization | +/- 95° |
| Standard Buc Options | 16W, 20W, 40W, 80W |
| RF Specifications |
|
| Midband Gain | 46.3 dBi (Tx); 45.3 dBi (Rx) |
| Environmental Specifications |
|
| Humidity | 0 - 100% condensing |
| Temperature Operational | -40°C to +60°C (Antenna) |
| Windspeed Operational | 72 mm/h (anchored) |
