Norsat RO120KUE040 Rover 1.2 m Ku-Band Manual Acquire Flyaway Antenna

Norsat RO120KUE040 Rover 1.2 m Ku-Band Manual Acquire Flyaway Antenna

Request for a quote

Norsat Rover 1.2 m Ku-Band Manual Acquire Flyaway Antenna

The ROVER™ is an ultra-lightweight fly-away satellite terminal with unsurpassed reliability, advanced assisted-acquire technology, and a flexible deployment platform. Available in both 1.0 and 1.2 m antenna sizes, the ROVER’s components can be tightly integrated for rapid deployment or separated into indoor and outdoor units for safe operation in dangerous terrain or situations. With IATA compliant packaging and a tool-free assembly process, the ROVER is easy to transport and operate, with military grade durability you can rely on wherever your mission takes you.

RO120KUE040 Key Specifications
Acquisition And Tracking Manual
Band Ku-Band
Product Family RO120KUE040
Receive Frequency Ku-Band: 10.95 - 12.75 GHz
Reflector Diameter 1.2 m
Transmit Frequency Ku-Band: 13.75 - 14.50 GHz
Antenna Specifications
Axial Ratio n/a
Azimuth Range +/- 300°, Manual with fine adjust
Cross Polarization Isolation >35 .0 dB within 1 dB contour
Elevation Range 5° to 85°, Manual with fine adjust
Feed Configuration 2-port circular
Polarization Linear Cross-Pol
Primary Antenna Power AC 110/220 VAC (50/60 Hz )
Standard Buc Options 4W, 8W, 16W, 20W, 40W, 80W
RF Specifications
Eirp 57.6 dBW
G T 20.2 dB/K
Max Ssg Variation +/- 1 dB per 54 MHz
Movement Platform Elevation over Azimuth
Reference Signal Frequency 0 +/- 5 dBm @ 10 MHz
Rx Gain >41.0 dBi (mid band)
Spectral Regrowth -26 dBc
Tx Gain >43.0 dBi (mid band)
Environmental Specifications
Humidity 5-95 % non-condensing, meets MIL-STD-810G
Rainfall Survival 30 mm/h, meets MIL-STD-810G
Salt Mist Meets MIL-STD-810G
Shock Meets MIL-STD-810G
Temperature Operational -30°C to +55 °C, meets MIL-STD-810G
Vibration Loose Cargo Meets MIL-STD-810G
Vibration Operational Meets MIL-STD-810G
Vibration Random Meets MIL-STD-810G
Windspeed Operational 60 km/h
Windspeed Survival 100 km/h
Physical Specifications
Iata Cases Available Optional
Number Of Cases 2 standard, 3 IATA
