Norsat 8515R Series C-Band Digital DRO LNB +/- 500 KHz
C-Band DRO LNB
Norsat 8515R Series C-Band Digital DRO LNB +/- 500 KHz As one of the early pioneers in the development of LNBs (satellite receivers), Norsat has long established a reputation for providing a full range of high quality, innovative LNB products....
- SKU::
- Category: All Products, C-Band LNBs, Low Noise Block LNB, Norsat
Norsat 8515R Series C-Band Digital DRO LNB +/- 500 KHz
As one of the early pioneers in the development of LNBs (satellite receivers), Norsat has long established a reputation for providing a full range of high quality, innovative LNB products. These LNBs convert and amplify the C-band, Ku-band or Ka-band signal to a lower Intermediate Frequency (IF) of L-band.
At Norsat we work with you to recommend products best suited for your application. We can provide specification sheets to assist in your decision and can offer custom LNB modifications if your project requires, for example, a unique frequency or connector. Price quotations are available on a variety of noise figures and L.O.
Input Frequency | 3.7 to 4.2 GHz |
Output Frequency | 950 – 1450 MHz |
Noise Temperature | 25°K |
Conversion Gain | 24 dB |
Output VSWR | 2.2:1 Typical, 75 ohm |
1-dB Compression Point | +8 dBm Min |
LO Frequency | 5.15 GHz |
LO Frequency Stability | ±500 KHz Typical; -40°C to +60°C |
Phase Noise | -70 dBc/Hz @ 1 KHz |
-90 dBc/Hz @ 10 KHz | |
-100 dBc/Hz @ 100 KHz | |
DC Feed | +15 to +24 VDC |
Current | 130 mA Max |
Operating Temperature | -40°C to +60°C |
Input Interface | Flange, WR 229G |
Output Interface | 75 Ohm, Type “F” Female |
Physical Size | 7.1 x 4 x 2.8 in |
