Norsat

Norsat 8515I Series C-Band DRO Digital LNB +/- 500 kHz

Norsat 8515I Series C-Band DRO Digital LNB +/- 500 kHz

Input Type
Request for a quote

SKU: NOR-8515IF

Norsat 8515I Series C-Band DRO Digital LNB +/- 500 kHz

  • (Discontinued model. replaced by 5250I)
  • Input Frequency: 4.5 – 4.8 GHz
  • Local Frequency: 5.95 GHz
  • Output Frequency: 1150 – 1450 MHz
  • Local Stability: ±500 kHz
  • Noise Temperature: 15K

The Norsat 8515i Series C-Band DRO LNB has a local oscillator frequency of 5.95 GHz and operates from 4.50 to 4.80 GHz. The 8515i LNB features a groundbreaking 15 K noise temperature rating. This DRO Norsat C-Band LNB has a CPR229 waveguide input and offers outstanding Local Oscillator (L.O.) stability of ±500 kHz.  F connector or Type-N Output.

Norsat 8515I Series C-Band DRO Digital LNB +/- 500 kHz

Model
  • Norsat 8515I
Input Frequency
  • 4.5 - 4.8 GHz
Local Frequency
  • 5.95 GHz
Local Stability
  • ±500 kHz
Noise Temperature
  • 15K
Output Frequency
  • 1150 - 1450 MHz
Phase Noise
  • -65 dBc/Hz @ 1 kHz
  • -80 dBc/Hz @ 10 kHz
  • -95 dBc/Hz @ 100 kHz
Input VSWR
  • 2.0:1
Output VSWR
  • 2.2:1
Gain
  • 64 dB
Output P1dB
  • 8 dBm
Power
  • 12 - 24V DC supplied through center conductor of IF cable
Current Drain
  • 130 mA
Input Waveguide
  • CPR 229G
Temperature Range
  • -40°C to +60°C
Dimensions
  • 7.1 x 4.0 x 2.8 Inches
Weight
  • 15 oz
