Norsat 8515 Series C-Band Digital DRO LNB

Norsat 8515 Series C-Band Digital DRO LNB

C-Band DRO LNB

Norsat 8515 Series C-Band Digital DRO LNB Input Frequency: 3.4 – 4.2 GHz Local Frequency: 5.15 GHz Output Frequency: 950 – 1750 MHz Local Stability: ±500 kHz Noise Temperature: 15K  Connectors:  F Female or N Female Norsat Satellite Communication solutions...

  • Category: All Products, C-Band LNBs, Low Noise Block LNB, Norsat

Norsat 8515 Series C-Band Digital DRO LNB

  • Input Frequency: 3.4 – 4.2 GHz
  • Local Frequency: 5.15 GHz
  • Output Frequency: 950 – 1750 MHz
  • Local Stability: ±500 kHz
  • Noise Temperature: 15K
  • Connectors:  F Female or N Female

Norsat Satellite Communication solutions are renowned for their high quality, reliability, and innovation. Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communication around the world.  Norsat LNBs feature:

  • - The industry’s best LO (Local Oscillator) stability
  • - High performance for any application
  • - Excellent availability and short lead times Stock units are available in standard and extended C-Band frequencies. Special order units are available in a wide variety of additional frequencies from 10.38 – 10.55 GHz up to 17.7 - 18.1 GHz.

Norsat 8515 Series C-Band Digital DRO LNB

Model
  • Norsat 8515
Input Frequency
  • 3.4 - 4.2 GHz
Local Frequency
  • 5.15 GHz
Local Stability
  • ±500 kHz
Noise Temperature
  • 15K
Output Frequency
  • 950 - 1750 MHz
Phase Noise
  • -65 dBc/Hz @ 1 kHz
  • -80 dBc/Hz @ 10 kHz
  • -95 dBc/Hz @ 100 kHz
Input VSWR
  • 2.0:1
Output VSWR
  • 2.2:1
Gain
  • 64 dB
Output P1dB
  • 8 dBm
Power
  • 12 - 24V DC supplied through center conductor of IF cable
Current Drain
  • 130 mA
Input Waveguide
  • CPR 229G
Temperature Range
  • -40°C to +60°C
Dimensions
  • 7.1 x 4.0 x 2.8 Inches
Weight
  • 15 oz
