Norsat 5700R Series C-Band PLL LNB +/-75 kHz
Norsat 5700R Series C-Band PLL LNB +/-75 kHz
Sale
Sold out
SKU: NOR-5700RF
Couldn't load pickup availability
Norsat 5700R Series C-Band PLL LNB +/-75 kHz F-Type
Ideal for DVB (Digital Video Broadcast), VSAT Broadband, Military Satcom, Point-of-Sale, and Oil and Gas applications
- Input Frequency: 3.7 - 4.2 GHz
- Output Frequency: 950 - 1450 MHz
- L.O. Stability: +/-75 kHz
- Noise Figure: .22 dB typical
- Output Connector: F-Type Female
- L.O. Frequency: 5.15 GHz
- Conversion Gain: 62 dB typical
TYPICAL SPECIFICATIONS
- L.O. stability ±150 kHz, ±250 kHz
- Noise temperature 15 K typ., 30 K max
- Phase noise -65 dBc/Hz @ 1 kHz offset -80 dBc/Hz @ 10 kHz offset -95 dBc/Hz @ 100 kHz offset
- Input VSWR & Output VSWR 2.5:1
- Conversion gain 62 dB typical 55 dB min 70 dB max
- Output P1dB 5 dBm
- Power requirements 12 - 24V DC supplied through center conductor of IF cable
- Current drain 250 mA
- Input Waveguide CPR 229G
- Dimensions 190 (L) x 115 (W) x 78 (H) mm (7.1 x 4.0 x 2.8 in)
- Weight 580 g / 20.5 oz
- Temperature Range -40°C to +60°C
