Norsat 5700 Series C-Band PLL LNB ±75 kHz

Norsat 5700 Series C-Band PLL LNB ±75 kHz

C-Band PLL LNB

Norsat 5700 Series C-Band PLL LNB +/-75 kHz Ideal for DVB (Digital Video Broadcast), VSAT Broadband, Military Satcom, Point-of-Sale, and Oil and Gas applications Input Frequency: 3.4 - 4.2 GHz L.O. Stability: +/-75 kHz Noise Figure: .22 dB typical Output...

  • Category: All Products, C-Band LNBs, Low Noise Block LNB, Norsat

Norsat 5700 Series C-Band PLL LNB +/-75 kHz

Ideal for DVB (Digital Video Broadcast), VSAT Broadband, Military Satcom, Point-of-Sale, and Oil and Gas applications

  • Input Frequency: 3.4 - 4.2 GHz
  • L.O. Stability: +/-75 kHz
  • Noise Figure: .22 dB typical
  • Output Connector: F-Type Female or N-Type Female
  • L.O. Frequency: 5.15 GHz
  • Conversion Gain: 62 dB typical

Norsat 5700 Series C-Band PLL LNB ±75 kHz

TYPICAL SPECIFICATIONS

  • L.O. stability ±50 kHz – ±100 kHz  depending on model number
  • Noise temperature 15 K typ., 30 K max.
  • Phase noise -65 dBc/Hz @ 1 kHz offset  -80 dBc/Hz @ 10 kHz offset  -95 dBc/Hz @ 100 kHz offset
  • Input VSWR & Output VSWR 2.3:1
  • Conversion gain 62 dB typical  55 dB min  70 dB max
  • Output P1dB 10 dBm
  • Power requirements 12 - 24V DC supplied through  center conductor of IF cable Current drain 250 mA
  • Input Waveguide CPR 229G
  • Dimensions 190 (L) x 115 (W) x 78 (H) mm  (7.1 x 4.0 x 2.8 in)
  • Weight 580 g / 20.5 oz
  • Temperature Range -40°C to +60°C
