Norsat 3020X Series Ext. Ref. PLL C-band LNB 3.4 - 4.2 GHz Input Frequency 20° K Noise Temperature L.O. Frequency 5.15 GHz Type F Connector The Norsat 3020X Series C-Band LNB is externally referenced, operates from 3.40 to 4.20 GHz,...

  • Category: All Products, C-Band LNBs, Low Noise Block LNB, Norsat

Norsat 3020X Series Ext. Ref. PLL C-band LNB

  • 3.4 - 4.2 GHz Input Frequency
  • 20° K Noise Temperature
  • L.O. Frequency 5.15 GHz
  • Type F Connector

The Norsat 3020X Series C-Band LNB is externally referenced, operates from 3.40 to 4.20 GHz, and delivers outstanding 20 K noise temperature stability.This externally referenced C-Band Norsat LNB has a precision CPR229 waveguide input and offers phase noise of 1 kHz, 10 kHz, and 100 kHz±5 kHz.

LNB Models

3020XF: "F" connector
3020XN: Type N

Norsat 3020X Series Ext. Ref. PLL C-band LNB

FREQUENCY BANDS AVAILABLE

Input frequency (GHz) 3.40 to 4.20
L.O. frequency (GHz) 5.15
Output frequency (MHz) 950 to 1750


TYPICAL SPECIFICATIONS

Noise temperature 20K
L.O. stability (over temperature excl offset) Phase Locked to External Reference
Gain Flatness (-40°C to +60°C) 1dBp-p @ 36 MHz
Gain Variation @ Fixed Freq. 6 dBp-p max
(-40°C to +60°C)
6 dBp-p max
Phase noise (SSB)
1kHz -73 dBc/Hz
10kHz -83 dBc/Hz
100kHz -93 dBc/Hz
Input VSWR 2.2 : 1
Output VSWR 2.2 : 1
Conversion gain 62 dB
Output P1dB 9 dBm
Power requirements +12 to +24 V supplied through center conductor of IF cable
Current drain 330 mA
Input Waveguide CPR229G
Dimensions 144 (L) x 70 (W) x 98 (H) mm
(5.7 x 2.8 x 3.9 in)
Weight 425 g / 15 oz
Temperature Range -40°C to +60°C
Relative Humidity 0 - 100% condensing
