Norsat 1507HC Ku Band PLL LNB

Norsat 1507HC Ku Band PLL LNB

Ku-Band PLL LNBs

FEATURES 10.95-11.70 GHz Input Frequency 0.7 dB Noise Figure ±5 kHz LO Stability Type F Connector (N Connector Option) KEY SPECIFICATIONS Product Family 1000 Series Band Ku-Band LO Type PLL # of onboard LOs Single-band LO Stability +/- 5 KHz Noise Figure 0.7...

USD 350.00
  • Category: All Products, Ku-Band LNBs, Low Noise Block LNB, Norsat

FEATURES

  • 10.95-11.70 GHz Input Frequency
  • 0.7 dB Noise Figure
  • ±5 kHz LO Stability
  • Type F Connector (N Connector Option)
KEY SPECIFICATIONS
Product Family 1000 Series
Band Ku-Band
LO Type PLL
# of onboard LOs Single-band
LO Stability +/- 5 KHz
Noise Figure 0.7 dBm
Input Frequency - Band 1 Ku-Band: 10.95 - 11.70 GHz
Output Frequency 1 L-Band: 950 - 1700 MHz

RF SPECIFICATIONS
LO Frequency 1 10.00 GHz
Phase Noise @ 1KHz offset -75 dBc/Hz
Phase Noise @ 10KHz offset -80 dBc/Hz
Phase Noise @ 100KHz offset -95 dBc/Hz
Conversion Gain 60 dB
Gain Variation over operating band 4dB p-p @ over 500 MHz
Gain Variation over temperature 6dB p-p max ( -40°C to +60°C)
Input VSWR 2.2 : 1
Output VSWR 2.2 : 1
Output P1dB compression point 5 dBm

ELECTRICAL SPECIFICATIONS
Power Requirements 15 - 24V DC
Current Drain 200 mA

INTERFACE SPECIFICATIONS
RF Input Connector WR75
RF Output Connector N-50 Ohm

M & C SPECIFICATIONS
LED Indicators None

ENVIRONMENTAL SPECIFICATIONS
Temperature - Operational -40°C to +60°C

PHYSICAL SPECIFICATIONS
Dimensions (L x W x H) 110 x 42 x 42 mm
Weight 300 g
