NJRC NJZ1287F 250W AC/DC BUC Power Supply Outdoor Unit

NJRC NJZ1287F 250W AC/DC BUC Power Supply Outdoor Unit

48V Power Supply

FEATURES Outdoor AC/DC Power Supply Unit  for Ku-16W BUCs  Maximum Output Power: 250 W Output Voltage: +48 VDC Universal Input AC Voltage Input AC Voltage: 100 to 240 V Active Power Factor Correction (PFC) Equipped Compact Size & Light Weight...

  • Category: All Products, Block Upconverter BUC, New Japan Radio, Power Supply

FEATURES

  • Outdoor AC/DC Power Supply Unit
      • for Ku-16W BUCs
    • Maximum Output Power: 250 W
    • Output Voltage: +48 VDC
  • Universal Input AC Voltage
    • Input AC Voltage: 100 to 240 V
  • Active Power Factor Correction (PFC) Equipped
  • Compact Size & Light Weight
  • RoHS Compliance

OVERVIEW

The features of Outdoor 250W AC/DC Power Supply Unit (PSU) are to provide the stable +48V DC power to operate Ku-band 16W BUC, even if power supply of the equipment is not capable enough to operate the BUC. This unit employs the aluminum housing with corrosion-proof treatment on the surface and has air-sealing structure in order to use perfectly as the outdoor unit.
In addition, the outdoor AC/DC PSU complies with EC DIRECTIVE.

Applicable Model



Interface



PERFORMANCE

Item Specifications
Interface (AC Input) AC Connector: C016 20C003 200 12
(DC Output) MS Connector: PT02E-14-12S(025)
(Option Port) MS Connector: PT02E-12-8P(025)
Input AC Voltage Rated Range: 100 to 240 VAC
Absolute Maximam Rating: 90 to 264 VAC
Input AC Frequency 50 / 60 Hz
Output Voltage +48 VDC nom.
Maximum Output Power 250 W
Efficiency 90 % typ. at 110 VAC, full load
Power Factor 0.90 typ. at 110 VAC, full load
Regulations * EU Directive (CE Marking)
    EMC (2004/108/EC)
    LOW VOLTAGE (2006/95/EC)
Waterproof / Dustproof (IP Code) IP 67 or equivalent
Weight 1.6 kg [3.5lbs]
