Nexgenwave NEX-800 C-Band DRO LNB
1 In stock
C-Band DRO LNB
Nexgenwave
Nexgenwave NEX-800 C-Band DRO LNB
- Noise temperature: 30 Kmax
- Input VSWR 2.5:1 max
- Image rejection 45dBc min.
- Conversion gain 65dB typ. 55dB min. 70dB max
- Output VSWR 2.5: 1 max
- Gain flatness 4dBp-p max
|
Parameter |
Specification |
|
Noise temperature (@+25'C) |
30‘K max. |
|
Input VSWR |
2.5 : 1 max. |
|
Image rejection |
45 dBc min. |
|
Conversion gain |
65dB typ. 55dB min. 70dB max. |
|
Output VSWR |
2.5 : 1 max. |
|
Gain flatness |
4 dBp-p max. |
|
Gain ripple (@per 27 MHz segment) |
+/- 0.5 dB max. |
|
1dB gain compression point |
+3 dBm min. |
|
Output impedance |
75 ohms |
|
Leakage (@ input port) |
-45 dBm max. |
|
Phase noise |
-65 dBc/Hz @1KHz offset |
|
Power supply |
+12 to +24V DC Required current |
|
Operating temperature |
-40'C to +60'C |
|
Storage temperature |
-40'C to +80'C |
|
Relative humidity |
0% to 95% RH |
|
Input waveguide flange |
WR- 229 |
|
IF output connector |
F-Type female |
|
Weight |
575 g |
