MFC 18323 INSAT C-Band Transmit Reject Filter

MFC 18323 INSAT C-Band Transmit Reject Filter

RF Filter

MFC 18323 Tx Rejection Model 18323 INSAT C-Band Transmit Reject filter offers extremely low loss, typically less than 0.5 dB on receive signals while providing a high degree of transmit rejection ranging from 80 dB Min from 6.725 - 7.025 GHz. Specifications:...

USD 235.00
  • Category: Accessories, All Products, RF Filter

MFC 18323 Tx Rejection

Model 18323 INSAT C-Band Transmit Reject filter offers extremely low loss, typically less than 0.5 dB on receive signals while providing a high degree of transmit rejection ranging from 80 dB Min from 6.725 - 7.025 GHz.

Specifications:

Passband:                6.725 - 7.025 GHz

Insertion Loss:         0.10 dB Approx

VSWR:                    1.22:1 Max

Reject Bands:           4.5 - 4.8 GHz

Rejection:                 80 dB Typ

Flanges:                   CPR137/CPR137G

Dimensions:             5.00" x 2.69" x 1.94"

(127mm x 68mm x 49mm)

Finish:                      White Lacquer
