MFC 16600 Super Extended C-Band Transmit Reject Filter

MFC 16600 Super Extended C-Band Transmit Reject Filter

RF Filter

MFC 16600 Transmit Rejection This Super Extended C-Band Transmit Reject filter offers extremely low loss, typically less than 0.1 dB on receive signals while providing a high degree of transmit rejection ranging from 80 dB Min from 5.825 - 7.250 GHz and...

  • Category: Accessories, All Products, Featured products, RF Filter

MFC 16600 Transmit Rejection

This Super Extended C-Band Transmit Reject filter offers extremely low loss, typically less than 0.1 dB on receive signals while providing a high degree of transmit rejection ranging from 80 dB Min from 5.825 - 7.250 GHz and 70 dB Min from 7.250 - 8.400 GHz

Specifications:

Passband:                   3.4 - 4.2 GHz

Insertion Loss:            0.1 dB Typ

Reject Band:               5.825 - 8.400 GHz

Rejection:                   80 dB Min from 5.825 - 7.250 GHz

70 dB Min from 7.250 - 8.400 GHz

Flanges:                      CPR229G

Pressure:                    5 PSI

Weight:                       3.75 lbs (1.7 Kg)

Dimensions:                11.0" x 3.88" x 2.75"

(279mm x 98mm x 70mm)

Finish:                         Flat Black Lacquer
