iDirect/ST Engineering iQ LTE Series

iDirect/ST Engineering iQ LTE Series

Request for a quote

The iQ LTE series is ideal for enterprise, maritime, and land mobility applications, the single box, converged solution combines high-performance iQ series features with an integrated LTE cellular modem for robust mobility connectivity reaching throughputs over 1000 Mbps on a cellular network and over 300 Mbps on a VSAT network, when being used in L2oS mode. Its licensable features enable the service provider to scale easily by adding more inbound throughput capabilities to the modem avoiding costly site visits or modem swap outs. The satellite modem will reach high return throughput capabilities due to high Msps rate (up to 15 Msps) on the inbound and supports higher power BUCs and OpenAMIP mobility. The modem’s ease of installation allows service providers to deploy their services quickly, in a cost-effective way.

Learn more about the iQ LTE Series Modem along with key use cases, such as Secure Banking and ATM Resiliency, First Responder and Mobile Command, and Maritime Applications.

Features of the iQ LTE Series

  • VSAT/LTE failover and failback
  • WAN link affinity steering
  • Advanced VPN connectivity
  • SD-WAN option
  • QoS setting or link choice (affinity)
  • NetCloud Manager
  • Dual-SIM card slot
  • DVB-S2/S2X (release dependent), ATDMA
  • Multicast Overlay
  • Mobility

VSAT & LTE Support

Network Topology

Rx

DVB-S2X*/ACM



DVB-S2*/ACM

Tx

Adaptive TDMA
Modulation

QPSK, 8PSK, 16APSK to 256APSK

QPSK, 8PSK, 16APSK, 32APSK

SS-BPSK, BPSK, QPSK, 8PSK, 16QAM*
FEC

Refer to the LBA guide

LDPC 1/4 - 8/9

2D 16-State 1/2 - 6/7
Symbol Rates

5 Msps to 100 Msps

1 Msps to 45 Msps

128 ksps to 15 Msps
Spread Spectrum*  SF: 2,4,8; Up to 7.5 Mcps
LTE WAN Features Failover/Failback, Load Balancing, Traffic steering w/ WAN Affinity, IP passthrough, QoS (DSCP and Priority Queuing
LTE Specifications Dual SIM w/ Auto-carrier selection, DC-HSPA+ failover
Model iQ LTE iQ LTE+  iQ LTE Pro
Modem IBR650C-150M IBR900-600M IBR900-1200M***
Throughput 150 Mbps 600 Mbps 1200 Mbps
Region TBD per region** Available in most North America Only - FirstNet Ready
Wifi Option none Wifi + GPS Wifi + GPS

Modem Interfaces

Tx Interface

Connector  F-Type 75 Ohm
Frequency range L-band 950 - 2150 MHz
TX level Pmax of +0 dBm to Pmin of -35dBm

Rx Interface

Connector  F-Type 75 Ohm
Frequency range L-band 950-2150 MHz

Cellular Interface

SMA, 50 Ohm
Dual-SIM card slot

Data / Management Interface

LAN: Two 10/100/1000 Mbps Ethernet Ports
RJ 45 Console

Management

LTE Management
Cradlepoint NetCloud Mngr, Web UI, API, CLI, SNMP, SMS control

Protocols Supported

TCP, UDP, ICMP, DHCP, NAT/PAT, DNS, ROHCv2, RIPv2, IGMPv2,
IGMPv3, ICMP, IPv4 (IPv6 over L2oS), L3, VRRP, BGP

Security

256-bit AES Link Encryption (optional)

Mechanical and Environmental

Size

W 44.5 cm x D 32 cm x H 4.45 cm
(W 17.5 in x 12.6 in x 1.75 in)

Weight

4.5 kg (10 lbs)
Temperature:

Operating 0° to +60°C (32° to +140°F)
Storage -40° to +85°C (-40° to +185°F)
Humidity

Operating 10 - 90% non-condensing
Storage 5 - 95% non-condensing

Power Supply

Input Voltage

100-240VAC, Auto-Ranging
36-76VDC (availability for DC pwr TBD)
