Product Overview
The Intellian OW10HM is designed for maritime applications, offering reliable connectivity for fishing, leisure, and small vessels. With its compact form factor and advanced tracking technology, the OW10HM ensures seamless communication even in challenging environments.
Key Features
- Optimized Performance: Delivers high performance in a compact design, ideal for SWaP-constrained maritime applications.
- Customer Network Exchange (CNX): Provides power and data connectivity with variants for specific maritime deployment scenarios.
- Seamless Connectivity: Advanced tracking technology ensures reliable handovers and connectivity, even in heavy seas.
- Harsh Environment Performance: Operates in extreme temperatures from -40 °C to +55 °C (-40 °F to +131 °F).
- Simplified Installation: Lightweight design allows for easy installation on poles, masts, and pedestals.
Specifications Table
| Category | Specification |
|---|---|
| Above Deck Unit | |
| G/T | 9 dB/k |
| EIRP | +36.6 dBW (Dual Carrier) |
| Dimensions | 56 x 45 x 12 cm (22” x 17.7” x 4.7”) |
| Weight | 12.2 kg (26.9 lb) |
| Operating Temp | -40 °C to +55 °C (-40 °F to +131 °F) |
| Ingress Protection | IP66 |
| Interface | F-Type Port, SMA Port (R-GNSS) |
| Peak Downlink Rate | 75 Mbps* |
| Peak Uplink Rate | 14 Mbps* |
| Below Deck Units | |
| CNX-BB Dimensions | 13 x 12 x 4 cm (5.1” x 4.7” x 1.6”) |
| CNX-WIFI Dimensions | 21 x 17 x 8 cm (8.2” x 6.7” x 3.1”) |
| CNX-MOBILITY Dimensions | 30 x 20 x 4 cm (11.8” x 7.9” x 1.6”) |
| CNX-RACK-AC Dimensions | 44.2 x 25 x 4.4 cm (19” x 1 RU chassis) |
| Weight | CNX-BB: 0.25 kg (0.55 lb); CNX-WIFI: 0.6 kg (1.3 lb); CNX-MOBILITY: 1.5 kg (3.3 lb); CNX-RACK-AC: 6.3 kg (13.9 lb) |
| Operating Temp | CNX-BB & CNX-WIFI: 0 °C to +40 °C (+32 °F to +104 °F); CNX-MOBILITY & CNX-RACK-AC: -25 °C to +55 °C (-13 °F to +131 °F) |
| Ingress Protection | IP44 (CNX-BB), IP56 (CNX-WIFI), IP31 (CNX-MOBILITY) |
| Interface | Various ports including GigE RJ45, F-type, WiFi-6 |
| Power Supply | External DC and AC options; embedded 450 W dual power modules available |
Ordering Information
The Intellian OW10HM is available through VSATPlus. Visit our website to learn more and place an order for this innovative connectivity solution.
Intellian OW10HM Datasheet
