IDIRECT EVOLUTION® X1 OUTDOOR SATELLITE ROUTER

Reliable, high-speed IP connectivity for large, narrowband networks

The iDirect Evolution X1 Outdoor Satellite Router is a Cost-effective remote bundle ideal for large-scale networks for SCADA, femtocells and pipeline monitoring. The remote features DVB-S2/ACM and Adaptive TDMA, routing, VLAN functionality, QoS, optional AES encryption and is embedded in a IP67 weatherproof enclosure enabling an extended temperature range, passive cooling and multiple power options, including DC.

EVOLUTION X1 HIGHLIGHTS

  • Star topology
  • DVB-S2/ACM outbound for greater efficiency and enhanced network availability
  • Deterministic MF-TDMA return channel
  • Optional IP67 enclosure to withstand extreme temperatures
  • AC or DC power supplies
  • Low cost of entry

Compact and cost-effective, the Evolution X1 Satellite Router features DVB-S2 and Adaptive Coding and Modulation (ACM) on the outbound and deterministic TDMA on the return to maximize bandwidth efficiency. The X1 outdoor version is low-powered, withstands extreme temperatures and is pole mountable for increased flexibility and convenience. The X1 also has a web-based iSite for ease of remote commissioning.

SPECIFICATION

X1 Network Configuration
Interfaces
SatCom Interfaces
    TxIF
    RxIF

Type-F, 950 - 1700 MHz, Composite Power 0dBm / -30dBm
Type-F, 950 - 2150MHz, Composite Power -5dBm / -65dBm
Available BUC Power (IFL) +24V, 25W max. supporting BUCs up to 3W (60W external PSU)
Available LNB Power (IFL) +24VDC, 22KHz DiSEqC tone
Data Interfaces LAN: 10/100 Ethernet
Web-based configuration via Ethernet port
Protocols Supported TCP, UDP, ICMP, DHCP, Local DNS Caching
Traffic Engineering QoS (Priority Queuing, Strict Priority Queuing, WFQ); Application-based QoS; Configurable Packet Classifier; CIR (Static and Dynamic), Minimum CIR, Idle/Dormant Min IR
Other Features Built-in Automatic Uplink Power Control, Frequency and Timing Control, Authentication, Remote Lock (to network)
Mechanical/Environmental
Size 10.25” x 3” x 10” in
Weight 5.0 lbs (2.27 Kg)
Operating Temperature -40° to 60°C (-40° to 140°F) at Sea Level
Humidity 5% - 92% non-condensing humidity
Immersion IP67/NEMA 6
Input Voltage 100-240 VAC to 24 VDC; 12/24 VDC to 24 VDC
Radio Standards EN 301-428v1.3.1 – Ku-Band System Level Specifications
EN 301-443v1.3.1 – C-Band System Level Specifications
Safety Standards Complies with IEC 60950, EN 60950, EN 60950-22 , UL 60950-1, CSA C222 NO.60950-1-03
Emission Standard Complies with EN 55022 Class B, FCC Part 15 Class B, EN 61000-3-2, EN 61000-3-3
EMC/Immunity Standard Complies with EN55024, EN301-489-1, EN 301-489-12, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN61000-4-11
Certification FCC, CE and RoHS compliant
