VSATplus International Inc.

iDirect iQ Desktop Satellite Router

Not Specified

Satellite Modem

iDirect

The iQ Desktop is part of iDirect’s DVB-S2*/S2X* remote series based on a future-proof hardware with software-defined architecture for maximum flexibility and expansion. The iQ Desktop is highly scalable and ideal for broadband access and small enterprise applications and is compatible on both Evolution® and iDirect Velocity®. Features: DVB-S2* (up to...
-
+
USD 450.00 from USD 425.00
USD 425.00
Add to wishlist
Tags: /

The iQ Desktop is part of iDirect’s DVB-S2*/S2X* remote series based on a future-proof hardware with software-defined architecture for maximum flexibility and expansion. The iQ Desktop is highly scalable and ideal for broadband access and small enterprise applications and is compatible on both Evolution® and iDirect Velocity®.

Features:

  • DVB-S2* (up to 45Msps) / DVB-S2X* (up to 100 Msps) outbound
  • MODCODs up to 256APSK
  • Adaptive TDMA return channel
  • Dual GigE ports:1 for user traffic and 1 for mgmt. traffic
  • 10 and 50MHz reference for BUC compatibility
  • 256-bit AES link encryption*

Network Configuration

Network Topology

DVB-S2*/S2X with Adaptive TDMA Returns



Downstream



Upstream



DVB-S2X/ACM

DVB-S2*/ACM

Adaptive TDMA

Modulation

QPSK, 8PSK, 16APSK, 32APSK, 64APSK, 128APSK, 256APSK

QPSK, 8PSK, 16APSK, 32APSK

BPSK, QPSK, 8PSK

Symbol Rates

5 to 119 Msps

1 to 45 Msps

128 ksps to 7.5 Msps





Interfaces

SatCom Interfaces

Tx: L-band/F-Type, 950-2400 MHz, 0dBm/-35dBm, 75Ω

Rx: L-band/F-Type, 950-2150MHz, 75 Ω

RF Power Transmit: Pmax of +0 dBm to Pmin of -35 dBm

RF Power Receive: Max composite wide band receive level:

a) -5 dBm for symbol rates ≤ 45 Msps

b) 10 dB above wanted signal power level for symbol rates > 45 Msps

Minimum Receive Level: -115+10*log (Fsym(sps)) single carrier



Available BUC Power (IFL)

+24V, 2.0A** max available @ connector Tx Out

Available LNB Power (IFL)

13, 18, 21V @ 0.5A**, 22kHz tone @ connector Rx in

Data Interfaces

LAN: Two 10/100/1000 Mbps Ethernet

I/O

RJ45 Console

Protocols Supported

TCP, UDP, ICMP, DHCP, NAT/PAT, DNS, ROHCv2, RIPv2, IGMPv2, IGMPv3, ICMP, IPv4 (IPv6 over L2oS), L3

Traffic Engineering

QoS, CIR (Static and Dynamic)

Licensable Features

Inbound throughput, 256-bit AES Encryption*

Mechanical/Environmental

Size

W 4.78 cm (1.88 in) x D 11.43 cm (4.5 in) x H 18.26 cm (7.19 in)

Weight

0.37 kg, (0.83lb)

Operating Temperature

0° to 40°C (32° to 104°F), 0° to 35°C (32° to 95°F) at 10,000 ft

Storage Temperature

-40° to +85°C (-40° to +185°F)

Operating Humidity

10-90% non-condensing

Storage Humidity

5-95% non-condensing

Input Voltage

100-240 VAC, 50-60Hz

Certifications

FCC, CE, TUV, and RoHS Compliant

** Feature is release dependent
**Combined Tx & Rx power not to exceed 50W
