iDirect 5350 iNFINITI Remote Satellite Router Modem

iDirect 5350 iNFINITI Remote Satellite Router Modem

Request for a quote
INFINITI 5350 SERIES SATELLITE ROUTER

The iDirect 5350 iNFINITI Series Satellite Router combines a flexible networking platform with the highest TCP/IP throughput in the industry.

Delivering Reliable and Fast Enterprise Class IP Broadband Connectivity

Developed specifically to support the business critical applications of enterprise customers, the iNFINITI 5000 Series combines a flexible networking platform to deploy tailored topologies and configurations to support end users’ most specific needs.

The 5000 series is a satellite router designed for easy deployment, integrating a satellite modem, IP router, TCP acceleration, and advanced QoS and prioritization capabilities.

The iNFINITI 5000 uses the high performance TDM on the outbound and iDirect’s patented, deterministic MF-TDMA on the inbound, delivering speeds up to 20 Mbps on the outbound and up to 6.5 Mbps on the inbound.

INFINITI 5000 KEY FEATURES
  • Star topology, Mesh and SCPC
  • High data rates 20 Mbps outbound, 6.5 Mbps return
  • Security and encryption
  • Built-in TCP and HTTP acceleration
  • Advanced QoS and prioritization
  • MF-TDMA return channel achieving 98% payload efficiency
  • Automatic End-to-End Uplink Power Control for higher network availability
  • High Flexibility
Supporting multiple topologies such as star, mesh, and hybrid networks as well as point-to-point SCPC enable maximum flexibility when it comes to the integration of a variety of applications into a single platform. Optional AES encryption will add strong data encryption to customize networks to the most demanding corporate requirements.

Superior Quality of Service

Flexible Quality of Service and prioritization capabilities allow network operators to not only prioritize traffic and applications over their networks but with iDirect’s state-of-the-art Group QoS they can determine traffic prioritization across multiple applications, multiple remotes and multiple sub-networks simultaneously, adding a new level of granularity for easier management of the most complex SLA’s and subscriber services.

Support for a rich set of IP protocols and features such as TCP, UDP, multicasting, NAT, VLAN tagging and DHCP guarantee compatibility with a wide range of applications when providing corporate network extensions.

Bandwidth Efficiencies

Supporting a wide variety of the most advanced turbo product codes (TPC) FECs, the 5000 series provides more flexibility for network design and optimization. Features such as TCP and HTTP acceleration and local DNS caching increase throughput performance, and maximize the user’s experience.

Simplicity

Operating with all iDirect hubs, the iNFINITI 5000 Series can be easily configured, monitored and controlled through the iVantage™ Network Management System, a complete suite of software-based tools for configuring, monitoring and controlling satellite networks from one location.
Network Configuration
Network Topology
    Star (TDM/TDMA with MF-TDMA)
    Star/Mesh* (TDM/TDMA with MF-TDMA)
    SCPC (IP Only)

Model 5100/5150
Model 5300/5350
5100/5150/5300/5350
Symbol Rates
    Downstream:
    Upstream:

64 ksps up to 11.5 Msps
64 ksps up to 2.875 Msps (5.75* Msps)
Modulation
    Downstream:
    Upstream:

QPSK (BPSK*, 8PSK*)
QPSK (BPSK*)
IP Data Rates
    Downstream:
    Upstream:

128 kbps - 18 Mbps
64 kbps - 4.2 Mbps (8.4* Mbps)
FEC
    Downstream:
    Upstream:

TPC Rate 0.879, 0.793, 0.533, 0.431*
TPC Rate 0.793, 0.66, 0.533, 0.431*
Eb/No
    3.9 Eb/No for 10-9
    4.6 Eb/No for 10-9
    4.8 Eb/No for 10-9
    5.4 Eb/No for 10-9

Quasi Error  Free @ 0.533 FEC
Quasi Error  Free @ 0.793 FEC
Quasi Error  Free @ 0.879 FEC
Quasi Error  Free @ 0.66 FEC
Interfaces
SatCom Interfaces
    TxIF:
    RxIF:
    TVRO:

Type-F, 950 - 1700 MHz, Composite Power +7dBm / -35dBm
Type-F, 950 - 1700 MHz, Composite Power -5dBm / -65dBm
Type-F, 950 - 1700 MHz
Available BUC Power (IFL) +24V @ 3.2 Amps (Nominal, Typically up to 5W BUC)
Available LNB Power (IFL) +19.5V (Nominal)
10 Mhz Reference Available
Data Interfaces
    LAN:
    RS-232:

Single 10/100 and 8-Port 10/100 Switch, 802.1q VLAN
RJ45 (for GPS or Console connection or Antenna Pointing)
Protocols Supported TCP, UDP, ICMP, IGMP, RIP Ver2, Static Routes, NAT, DHCP, DHCP Helper, Local DNS Caching, cRTP
Traffic Engineering QoS (CBWFQ), Minimum CIR, CIR (Static and Dynamic), Rate Limiting, Bandwidth on Demand
Other Features Built-in Automatic Uplink Power, Frequency and Timing Control Adaptive Inbound Channel*
Security AES or 3DES Link Encryption (Optional ? Model 5150 and 5350)
Mechanical / Environmental
Dimensions (W x D x H) 11.375 in x 9.5 in x 2 in
(28.9 cm x 24.1 cm x 5.1 cm)
Weight 10 lbs (Including Power Supply) [4.6 Kg]
Rack Mounting 19" Rack Mountable, 19" Wide x 3.44" High (2U) x 11.5" Deep
Operating Temperature 0° to 50°C (+32°to +122°F) at Sea Level
0° to 45°C (+32° to +113°F) at 10,000 Feet
Input Voltage 100-240 VAC Universal Input, 50-60 Hz, 2A Max @ 100VAC
* Planned for future release. Specifications subject to change without notice
