ETL System DIV08L1A-2334 8-way L-band Active Splitter
ETL System DIV08L1A-2334 8-way L-band Active Splitter
Active Splitter
DIV08L1A-2334 is 8-way active L-band splitter with unity gain. 10MHz/DC pass on port 1 and DC block on all other ports. It requires 8-18V external DC bias. Applications: Typical fields of applications are telecom infrastructures, satellite systems, microwave links, test...
USD 285.00
- SKU::
- Category: Accessories, All Products, RF Combiner/Splitter
DIV08L1A-2334 is 8-way active L-band splitter with unity gain. 10MHz/DC pass on port 1 and DC block on all other ports. It requires 8-18V external DC bias.
Applications: Typical fields of applications are telecom infrastructures, satellite systems, microwave links, test and instrumentation and radar networks.
|
Maximum acceptable operating parameters for reliable and safe operation |
||
|
Parameter |
Value |
Comment |
|
Input RF power |
16dBm |
Max total RF power |
|
DC Voltage |
18V |
Any RF port |
|
Operating temperature |
0 to 50°C |
Indoor use only |
|
Storage Temperature |
-40°C to +85°C |
|
|
Humidity |
80% |
Non-condensing |
|
Altitude |
10,000 feet |
Above Mean See level |
|
! Operation beyond these limits may cause instantaneous and permanent damage. |
||
